Paper and Media
68 Xerox
®
WorkCentre
®
EC7836/EC7856 Color Multifunction Printer
User Guide
Loading Labels in Trays 1–4
1. Pull out the tray until it stops.
2. Ensure that the guide locks are set in the correct position for the size labels you are loading. For
details, see Setting the Guide Locks in the 500-Sheet Adjustable Trays on page 56.
Note: Trays 1–4 accept labels (106–169 g/m²).
For long-edge feed, load labels face up with the top edge toward the front of the tray.
3. For short-edge feed, load labels face up with the top edge facing to the right.
4. Close the tray. Set the paper size, type, and color at the control panel. For details, see Changing Paper
Size, Type, and Color on page 64.
