Xerox WorkCentre PE16 Service Manual

7-19
WorkCentre PE16
Troubleshooting
Service Manual
July 2003
7.4.5 Defective FAX RECEIVE (1)
• Description SEND is functioning, but RECEIVE is not functioning or the received data are broken.
Check and Cause Solution
1. Check if there is NOISE when pressing on-hook
dial.
2. Check the RECEIVE condition by receive a FAX at
another fax machine.
1. If NOISE is present while on-hooking, replace the tele-
phone line cord.
Check and Cause Solution
1. Check if there is noise when pressing on-hook
dial.
2. Ask to the sending side, to check the image quality
of a FAX received from another machine.
1. If noise is present, replace the telephone line cord.
(Refer to ‘Defective FAX RECEIVE’.)
2. Check if the FAX status of the sending side is normal.
Check and Cause Solution
Check if the RECEIVE Mode is TEL MODE or FAX
MODE.
After the RECEIVE mode is changed to FAX MODE, if it
cannot receive, replace the LIU PBA and the Main PBA in
sequence.
7.4.6 Defective FAX RECEIVE (2)
• Description The received data are lengthened or cut in the printing.
7.4.7 Defective FAX RECEIVE (3)
• Description The phone is ringing continuously, but it cannot receive.
