EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
OPE Unit Assembly Parts List
No. Description Part Number Q’ty Remark
0 ELA HOU-OPE 101 N 01338 1
1 COVER-M-OPE(4IN1) 002 N 02198 1
2 KEY-M-RESOLUTION 003 N 00890 1
3 KEY-M-COPY 003 N 00891 1
4 KEY-M-SCROLL 003 N 00892 1
5 KEY-M-STOP 003 N 00893 1
6 KEY-M-START 003 N 00894 1
7 KEY-M-TEL 003 N 00895 1
8 KEY-M-FAX 003 N 00896 1
9 KEY-M-TONER SAVE 003 N 00897 1
10 KEY-M-TOLL SAVE 003 N 00898 1
11 RUBBER-COPY 003 N 00899 1
12 RUBBER-SCROLL 003 N 00900 1
13 RUBBER-TEL/FAX 003 N 00901 1
15 PBA SUB-OPE 140 N 62754 1
S SCREW-TAPTITE * 7 Not Spared
