EXPLODED VIEW & PA RTS LIST
Service Manual
June 2003 WorkCentre PE16
Frame Assembly Parts List
No. Description Part Number Q’ty Remark
0 ELA HOU-UNIT FRAME_110V 001 N 00407 1 110V
ELA HOU-UNIT FRAME_220V 001 N 00408 1 220V
1 FRAME-M-BASE * 1 Not Spared
2 GUIDE-P-TR 038 N 00407 1
3 PLATE-P-SAW 015 N 00500 1
4 GUIDE-M-TR RIB 038 N 00408 1
5 PMO-GEAR_EXIT_DRV16 * 2 Not Spared
6 RING-CS * 3 Not Spared
7 RMO-RUBBER_FOOT * 2 Not Spared
8 IPR-P-GROUND_TR * 1 Not Spared
9 MEC-TERMINAL * 4 Not Spared
10 IPR-P-TERMINAL CON * 3 Not Spared
11 IPR-P-TERMINAL CR * 1 Not Spared
12 HOUSING-TERMINAL 101 N 01346 1
13 PMO-LOCKER CST 120 N 00427 2
14 PMO-ACTUATOR CVR OPEN 120 N 00423 1
15 PMO-PLATE GUIDE DEVE_R 032 N 00390 1
16 SPRING ETC-GUIDE DEVE * 2 Not Spared
17 IPR-P-GROUND_GUIDE PAPER * 1 Not Spared
18 PMO-PLATE GUIDE DEVE_L 032 N 00391 1
19 PMO-ACTUATOR FEED 120 N 00424 1
20 PMO-ACTUATOR EMPTY 120 N 00425 1
21 PMO-ACTUATOR MANUAL 700 N 00093 1
22 IPR-P-GROUND_EARTH TR * 1 Not Spared
23 SPRING-ETC 009 N 01428 1
24 ROLLER-FEED ROLLER 1 * 1 Not Spared
25 PMO-BUSHING FEED * 5 Not Spared
26 SHAFT-FEED * 1 Not Spared
27 AS-PICK UP 022 N 01608 1
27-1 BUSH-M-PICK_UP L * 1 Not Spared
27-2 SHAFT-P-PICK_UP * 1 Not Spared
27-3 STOPPER-PICK_UP * 2 Not Spared
27-4 PMO-IDLE PICK_UP * 2 Not Spared
27-5 SPONGE-ROLLER PICK_UP 022 N 02016 1
27-6 BUSH-M-PICK_UP R * 1 Not Spared
27-7 HOUSING-M-PICK_UP * 1 Not Spared
28 IPR-P-EARTH TRANSFER 117 N 01616 1
29 HOLDER-PTL * 1 Not Spared
30 LENS-PTL 062 N 00246 1
