EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
Frame Assembly Parts List(Cont.)
No. Description Part Number Q’ty Remark
31 BUSH-M-TR L 016 N 00261 1
32 SPRING ETC-TR L HAWK * 1 Not Spared
33 ROLLER-FEED 022 N 01607 1
34 PMO-BUSHING_TR(L) 016 N 00254 1
35 IPR-P-GROUND_FUSER * 1 Not Spared
36 SHAFT-FEED IDLE * 1 Not Spared
37 BUSH-M-FEED IDLE * 2 Not Spared
38 SPRING ETC-TR * 2 Not Spared
39 IPR-P_GROUND_DRIVE2 007 N 01211 1
40 SPRING-TS * 1 Not Spared
41 CAM-M-PICK_UP 008 N 01738 1
42 IPR-P-GROUND_DRIVE * 1 Not Spared
43 SOLENOID-HB (PICK-UP) 121 N 00631 1
44 SOLENOID-HB (MANUAL) 700 N 00094 1
45 AS-GEAR PICK_UP 007 N 01212 1
45-1 PMO-GEAR PICK_UP B * 1 Not Spared
45-2 PMO-GEAR PICK_UP A * 1 Not Spared
45-3 SPRING-CS * 1 Not Spared
46 BRACKET-P-FEED 030 N 00656 1
47 MEA UNIT-CLUTCH 022 N 01609 1
47-1 GEAR-FEED 1 * 1 Not Spared
47-2 PMO-COLLAR_SPRING * 1 Not Spared
47-3 SPRING-TS * 1 Not Spared
47-4 PMO-HUB CLUTCH * 1 Not Spared
47-5 SHAFT-FEED * 1 Not Spared
48 ELA HOU-FUSER 110V, ROCKY 126 N 00214 1 110V
ELA HOU-FUSER 220V, ROCKY 126 N 00215 1 220V
49 GUIDE-P-PAPER 038 N 00409 1
50 GEAR-FEED 2 * 1 Not Spared
51 GEAR-IDLE 23 * 1 Not Spared
52 SPRING-TS * 1 Not Spared
53 SPRING-TS * 1 Not Spared
54 IPR-P-TERMINAL DEVE KEY * 2 Not Spared
55 CBF HARNESS-OPC_FUSE * 1 Not Spared
56 PBA MAIN-PTL 140 N 62757 1
S SCREW-TAPTITE * 9 Not Spared
S SCREW-TAPTITE * 12 Not Spared
S SCREW-ASS? TAPT * 3 Not Spared
