Cassette Assembly Parts List
No. Description Part Number Q’ty Remark
0 MEA UNIT-CASSETTE, USA 050 N 00427 1
1 FRAME-M_CASSETTE * 1 Not Spared
2 PMO-EXTENSION LARGE * 1 Not Spared
3 PMO-EXTENSION SMALL * 1 Not Spared
4 PLATE-P-KNOCK_UP * 1 Not Spared
5 SPRING-CS * 2 Not Spared
6 HOLDER-M-PAD * 1 Not Spared
7 SPRING ETC-EXIT ROLL FD * 1 Not Spared
8 ROLLER-M-IDLE FEED * 2 Not Spared
9 SPRING-ES * 2 Not Spared
10 PMO-PLATE_LOCKER * 1 Not Spared
11 SPRING ETC-LOCKER,PLATE * 1 Not Spared
12 ADJUST-M-CASSETTE_L * 1 Not Spared
13 ADJUST-M-CASSETTE_R * 1 Not Spared
14 GEAR-PINION * 1 Not Spared
15 INDICATOR-M-LEVER INDICATOR 018 N 00182 1
16 RPR-FRICTION PAD 019 N 00742 1
17 IPR-PLATE PAD * 1 Not Spared
18 RPR-PAD CASSETTE * 3 Not Spared
8-21
EXPLODED VIEW & PA RTS LIST
Service Manual
WorkCentre PE16 June 2003
