Xerox WorkCentre PE16 Service Manual

1) Open the document cover. 2) Turn the release knob so that you can easily remove
the misfed document. Remove the document from
the ADF or the feed area by carefully pulling it
towards the right by using both hands.
3) Close the document cover. Then load the documents
back into the ADF.
6-5
ALIGNMENT & ADJUSTMENTS
Service Manual
WorkCentre PE16 July 2003
6.2.1.2 Exit Misfeed
1) Open the document cover and turn the release knob to remove the misfed documents from the exit area.
2) Close the document cover. Then load the documents back into the ADF.
6.2.1.3 Roller Misfeed
