85
Appendix A.
POST Codes for Tritium Platform
This section provides the Award POST Codes (Table 6) and the NVMM POST
Codes (Table 7) for Tritium platforms during system boot up.
Table 6. Award POST Code
Award POST Codes
Co
de
Name Description
01 Reserved
02
Jumps to E000
segment
Execution of POST routines in E000
03 Early SuperIO Init Early Initialized the super IO
04 Reserved
05 Blank video Reset Video controller
06 Reserved
07 Init KBC Keyboard controller init
08 KB test Test the Keyboard
09 Reserved
0A Mouse Init Initialized the mouse
0B Reserved
0C Reserved
0D Reserved
0E CheckSum Check Check the integrity of the ROM,BIOS and message
0F Reserved
10
Autodetect
EEPROM
Check Flash type and copy flash write/erase routines
11 Reserved
