Xiaomi mi G10 Plus - Battery Status Indicator

To Next Page

To Previous Page

7 8

Display Screen

The number on the display screen represents the current battery level in a

percentage during charging. When the number turns into 100, the battery is

fully charged.

When the vacuum cleaner is being charged, you can press the power button to

wake up the display and check the current charging percentage.

Charging

Notes:

Fully charge the vacuum cleaner before using it for the first time. This will take

about 4 hours.

The vacuum cleaner cannot be used while charging.

Vacuuming at the highest suction level for a prolonged period will cause the

battery to heat up, which may increase the charging time. Before charging the

vacuum cleaner, it is better to cool it down for 30 minutes.

Battery Status Indicator

Once the vacuum cleaner is fully charged, the indicator will turn off after 5 minutes, and the

vacuum cleaner will then enter the energy-saving mode.

Note: means off, means on, and means blinking.

Low battery

Fully charged

Half battery

Nearly full

Charging the vacuum cleaner with the charger

Battery Status Indicator

Charging the vacuum cleaner on the charging mount

Charging Contact

Installing the 2-in-1 Charging & Storage Mount

1. The 2-in-1 charging & storage mount should be installed in a cool, dry place with an electrical outlet nearby. Prior to installing, ensure that there are not any wires

or pipes in the space directly behind where the mount will be installed.

2. The bottom of the mounting template sticker should be level and at least 103 cm from the ground, and its top should have at least 30 cm of clearance above it.

3. Use a power drill with an 8 mm drill bit to drill a hole into each hole marker on the mounting template sticker, then insert a wall plug into each hole.

4. Align the mounting holes on the 2-in-1 charging & storage mount to the holes on the wall, then attach the mount to the wall using the included screws.
