4. Remove the pre-filter first, then lift the handle of the cyclone assembly
and turn to counterclockwise until it stops, then pull to lift out the cyclone
assembly.
5. Rinse the pre-filter, cyclone assembly, and dust compartment with water
until they are clean, then set each component aside to thoroughly dry for at
least 24 hours.
Notes:
The dust compartment should be rinsed out at least once a month.
The pre-filter and cyclone assembly should be cleaned once every 3 to 4
months.
Pre-filter
Cyclone Assembly Dust Compartment
Pre-filter
3
1
2
2. Press the dust compartment bottom cover release button, then empty the
contents.
2
1
3. Pull the dust compartment release switch in the direction illustrated, then
remove the dust compartment from the vacuum cleaner.
Dust Compartment Release Switch
1
2
