Chapter 2
Unpacking
Accelerator Card Overview
Card Interfaces and Details
Alveo™ cards are available in both passive and acve cooling conguraons; see Passive and
Acve Cooling Cards. The interfaces of each are idencal, except the fan included on acve
cooled cards. The card includes the following interfaces, and are shown in the following gure:
1. A PCI Express
®
card connector.
2. A PCI Express Auxiliary Power Connector. This connector is shown in Figure 4. Connector is
not compable with an ATX12V/EPS12V power source.
3. Two QSFP interfaces. Currently these interfaces are not supported by the deployment
plaorm.
4. A Micro-USB connector for maintenance purposes.
5. A fan for the acve cooled card conguraon.
WARNING! Hazardous moving parts. Keep away from fan blades.
ATTENTION! Pièces mobiles peuvent etre dangereuses. Éloignez-vous des lames du venlateur.
WARNUNG! Gefährliche bewegliche Teile. Halten sie sich von Lüerügeln fern.
Chapter 2: Unpacking
UG1301 (v1.5) June 3, 2020 www.xilinx.com
Getting Started with Alveo Accelerator Cards 9
