10 www.xilinx.com AC701 Getting Started Guide
UG967 (v3.0) July 10, 2013
Basic Hardware Bring-up with Built-In Self-Test
Install the Silicon Labs UART Device Driver.
1. Run the downloaded executable UART-USB driver file, listed in Test Setup
Requirements (see Figure 5). This enables UART-USB communications with a host PC.
X-Ref Target - Figure 4
Figure 4: AC701 Board with UART and 12V Adapter Cables Attached
UG967_04_111412
X-Ref Target - Figure 5
Figure 5: UART Cable Driver Installation Dialog
UG967_05_111412
