Xilinx Kintex-7 FPGA KC705 User Manual

KC705 Getting Started Guide www.xilinx.com 7
UG883 (v4.0.1) May 28, 2014
Getting Started with the
Kintex-7 FPGA KC705 Evaluation Kit
(Vivado Design Suite 2013.2)
Introduction
The Kintex®-7 FPGA KC705 evaluation kit provides a comprehensive, high-performance
development and demonstration platform using the Kintex-7 FPGA family for
high-bandwidth and high-performance applications in multiple market segments. The kit
enables designing with DDR3, I/O expansion through FMC, and common serial
standards, such as PCI Express®, XAUI, and proprietary serial standards through the SMA
interface. See the KC705 Evaluation Board for the Kintex-7 FPGA User Guide (UG810
) and the
KC705 support website
.
The built-in self-test (BIST) and Kintex-7 FPGA Base Targeted Reference Design (TRD) are
developed on this kit.
This Getting Started Guide is divided into two sections:
• Basic Hardware Bring-up: Enables hands-on operation of all the features in the BIST
as well as evaluation of Analog Mixed Signal (AMS) using the AMS101 evaluation
card.
• Advanced Operation: Enables hands-on operation with the base TRD, which features
PCIe, DDR3 memory, and AXI—all supported through a custom evaluation graphical
user interface (GUI).
Send Feedback

Xilinx Kintex-7 FPGA KC705 Specifications

General

FPGA Speed Grade	-2
FPGA Package	FFG900
Logic Cells	326, 080
DSP Slices	840
Clock Management Tiles	10
Transceivers	16
DDR3 Memory	1GB
Flash Memory	128MB
Clock	200 MHz oscillator
Form Factor	ATX
Ethernet	10/100/1000
Expansion Connectors	FMC
USB	USB-UART
