Xilinx Mimas Spartan 6 FPGA User Manual

Header Pin No. Pin description
Spartan-6 (XC6SLX9 TQG144)
Pin No.
3 IO_L1P_3 35
4 IO_L1N_VREF_3 34
5 IO_L2P_3 33
6 IO_L2N_3 32
7 IO_L36P_3 30
8 IO_L36N_3 29
9 IO_L37P_3 27
10 IO_L37N_3 26
11 IO_L41P_GCLK27_3 24
12 IO_L41N_GCLK26_3 23
13 IO_L42P_GCLK25_TRDY2_3 22
14 IO_L42N_GCLK24_3 21
15 IO_L43P_GCLK23_3 17
16 IO_L43N_GCLK22_IRDY2_3 16
17 IO_L44P_GCLK21_3 15
18 IO_L44N_GCLK20_3 14
19 IO_L49P_3 12
20 IO_L49N_3 11
21 IO_L50P_3 10
22 IO_L50N_3 9
23 IO_L51P_3 8
24 IO_L51N_3 7
25 IO_L52P_3 6
26 IO_L52N_3 5
27 IO_L83P_3 2
28 IO_L83N_VREF_3 1
29 IO_L2P_0 142
30 IO_L2N_0 141
31 IO_L3P_0 140
32 IO_L3N_0 139
33 IO_L4P_0 138
34 IO_L4N_0 137
35 IO_L34P_GCLK19_0 134
36 IO_L34N_GCLK18_0 133


Xilinx Mimas Spartan 6 FPGA Specifications

General

Brand	Xilinx
Model	Mimas Spartan 6 FPGA
Category	Motherboard
Language	English

Summary

1. Introduction

2. How to Use Mimas – Spartan 6 FPGA Development Board

2.1. Components/Tools Required

Lists essential items for board installation and fast setup.

2.2. Connection Diagram

Visual representation of how to connect the board and its components.

2.3. USB Interface

2.4. DC Power Supply

2.5. Power Select

2.6. On-Board Peripherals

2.7. JTAG Connector

2.8. GPIOS

3. Driver Installation

3.1. Installing on Windows

Instructions for downloading and installing the driver package for Windows, appearing as a serial port.

3.2. Installing on Linux

Information on Linux driver installation, often pre-compiled in the kernel.

3.3. Installing on Mac

4. Generating Bit Stream for Mimas

5. Powering Up Mimas

6. Configuring Mimas

6.1. Configuring Mimas Using Configuration Tool

Steps to use the Mimas configuration tool via USB for programming the SPI flash.

6.2. Configuring Mimas Using JTAG

7. Programming FPGA Using ISE IMPACT

8. Technical Specifications

9. Mechanical Dimensions

10. Schematics
