Test Details
˃ Ensure that you have followed all instructions in XTP497, ZCU106 Software
Install and Board Setup
˃ Ensure that no other Terminal program is connected to the ZCU106’s COM
ports while the Board Interface Test is running
See XTP497, for details on COM Ports
˃ Only one board can be connected to your PC during the test
Both USB UART (J83) and USB JTAG (J2) are required for this test
Disconnect any other board UARTs or Programming Cables
˃ If you missed any set-up instructions and experience problems, then please
follow these steps:
Recheck your setup
End any hw_server processes and cycle board power
Open Vivado Hardware Manager and test PC-board JTAG connectivity
Note: Presentation applies to the ZCU106
