Test Details
˃ Review the following pages to make sure the board is set up for the
Production Board Interface Test
˃ Ensure that no other Terminal program is connected to the ZCU106’s COM
ports while the Board Interface Test is running
See XTP497, for details on COM Ports
˃ Only one board can be connected to your PC during the test
Disconnect any other board UARTs or Programming Cables
˃ If you missed any set-up instructions and experience problems, then please
follow these steps:
Recheck your setup
End any hw_server processes and cycle board power
Open Vivado Hardware Manager and test PC-board JTAG connectivity
Note: Presentation applies to the ZCU106
