Optional Test Equipment
˃ This test requires optional equipment
2ea Whizz FMC XM107 boards
‒ Attach to HPC0 (J5) and HPC1 (J4)
Whizz PCIe Loopback
‒ Connect to USB Power source
‒ Attached to PCIe fingers (P3)
˃ Linux tests optional equipment
4k HDMI source; tested with NVIDIA 4K Shield
‒ Attach Source to bottom port of P7
HDMI and DP monitors plus cables
‒ Tested with LG 27MU67-B monitor
‒ Attach HDMI monitor to top port of P7
‒ Attach DP monitor to P11
USB Thumb drive; tested with SDCZ43 32GB
A generic SATA Flash drive; formatted Win95 FAT32 (LBA)
‒ Will require power supply and SATA cable
‒ Connect SATA cable to P9
Two SD cards, programmed with the contents
of SATA_SD, and HDMI_Input
Note: Linux tests not included in this release; see prior version for Linux tests.
