Xilinx ZCU106

Optional Test Equipment
˃ This test requires optional equipment
EZ-11B or EZ-22B remote power switch, setup to IP address of 192.168.0.12
‒ Setup details are available later in this Appendix
‒ If this is not available, the following tests will require manual power cycling:
 SYS_CTLR_RESTORE
 XM107 CARD TEST
 ZCU106 RTC
 Test Level Shifters
 ZCU106 SETUP
 Program QSPI Flash
 Eth/SD/USB/SATA/VIDEO Test
 HDMI Input/Output
 Test QSPI Flash
Note: EZ11B not used in this release.
