132
P2-73
First notch bandwidth
0
Hz
01000
Anytime
At once
P2-74
Second notch frequency
5000
Hz
505000
Anytime
At once
P2-75
Second notch attenuation
70
0.1dB
501000
Anytime
At once
P2-76
Second notch bandwidth
0
Hz
01000
Anytime
At once
P2-77
Third notch frequency
5000
Hz
505000
Anytime
At once
P2-78
Third notch attenuation
70
0.1dB
501000
Anytime
At once
P2-79
Third notch bandwidth
0
Hz
01000
Anytime
At once
P2-80
Fourth notch frequency
5000
Hz
505000
Anytime
At once
P2-81
Fourth notch attenuation
70
0.1dB
501000
Anytime
At once
P2-82
Fourth notch bandwidth
0
Hz
01000
Anytime
At once
P2-83
Fifth notch frequency
5000
Hz
505000
Anytime
At once
P2-84
Fifth notch attenuation
70
0.1dB
501000
Anytime
At once
P2-85
Fifth notch bandwidth
0
Hz
01000
Anytime
At once
Note:
1. In the adaptive mode, if the vibration is detected, the second notch filter will be automatically configured.
2. In the auto-tuning mode, the second and first notches will be automatically configured if the vibration is
detected (the second notches will be preferentially opened when there is only one vibration point).
3. Whether in self-adaptive or auto-tuning mode, if the mechanical characteristic analysis is sued, it belongs to
manual setting of notches, please configure the third to fifth notches.
