supply of the driver, check the
connection of the encoder cable, if
there is cable loosening, it is
recommended to use the multimeter
to test the conduction condition;
after eliminating errors, power on
again
Hot plugging is strictly prohibited,
and special cables are required for
tank chains.
Main
type
Sub
type
Code
Description
Reasons
Solutions
22
0
E-220
Communication
error of
absolute servo
encoder
Received encoder data
errors, and the number of
errors exceeds the
number of error retries of
encoder registers P0-56
Check whether the value of U0-79 and
U0-54 increase. If yes, the encoder is
interfered. Encoder wire and strong
power do not have the same pipeline
wiring; install filter on servo driver power
input side; encoder wire sleeves magnetic
ring; shut down welding machine type of
equipment with large interference
1
E-221
Too many CRC
errors in
encoder
communication
The received encoder
data is wrong and the
number of errors exceeds
the value in encoder error
retry number register
P0-56
Encoder interfered, isolate interference
source
2
E-222
Absolute value
servo encoder
battery low
voltage alarm
(can shield this
alarm)
Battery Voltage in
Battery Box of Encoder
cable is less than 2.75V
Please replace the battery while keeping
the power supply ON of the servo driver
in order to avoid the error of encoder
position information. Battery
specification: No.5 battery, 3.6V (model
CP-B-BATT, CPT-B-BATT)
Power on alarm for new
machine
(1) When the absolute value motor is
powered off, the memory position
depends on the battery on the encoder
cable. Once the encoder cable and the
motor are disconnected, the power supply
can not be carried out, which will lead to
the loss of the current position of the
motor, it will alarm 222. Please set
F0-00=1 to clear the alarm, it can be used
normally.
(2) The alarm can be shielded by using
P0-79. When P0-79 is set to 1, it will be
used as a single-loop absolute value
motor, and the current position will not be
remembered when power off.
3
E-223
Data access
alarm of
absolute value
servo encoder
Encoder cable with
battery box is not used
for multi-turn absolute
motor
① Please use encoder cable with battery
box;
② Power off and power on again (the
driver panel shall be completely off). If
the alarm cannot be removed, please
contact the agent or manufacturer
Generally, it is the
problem of the encoder
itself, or the power
supply of the encoder is
unstable
Abnormal power on of
main control chip of
