Page #159 background imageLoading...
Page #159 background image
151
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
P2-69.0
Notch filter 1 switch
-
0
0~1
1|3|5|6|7
5.4.6
P2-69.1
Notch filter 2 switch
-
0
0~1
1|3|5|6|7
5.4.6
P2-69.3
Notch filter 3 switch
-
0
0~1
1|3|5|6|7
-
P2-70.0
Notch filter 4 switch
-
0
0~1
1|3|5|6|7
-
P2-70.1
Notch filter 5 switch
-
0
0~1
1|3|5|6|7
-
P2-71
First notch frequency
Hz
5000
50~5000
1|3|5|6|7
5.7.7
P2-72
First notch attenuation
0.1dB
70
50~1000
1|3|5|6|7
5.7.7
P2-73
First notch band width
Hz
0
0~1000
1|3|5|6|7
5.7.7
P2-74
Second notch frequency
Hz
5000
50~5000
1|3|5|6|7
5.7.7
P2-75
Second notch attenuation
0.1dB
70
50~1000
1|3|5|6|7
5.7.7
P2-76
Second notch band width
Hz
0
0~1000
1|3|5|6|7
5.7.7
P2-77
Third notch frequency
Hz
5000
50~5000
1|3|5|6|7
5.7.7
P2-78
Third notch attenuation
0.1dB
70
50~1000
1|3|5|6|7
5.7.7
P2-79
Third notch band width
Hz
0
0~1000
1|3|5|6|7
5.7.7
P2-80
Fourth notch frequency
Hz
5000
50~5000
1|3|5|6|7
5.7.7
P2-81
Fourth notch attenuation
0.1dB
70
50~1000
1|3|5|6|7
5.7.7
P2-82
Fourth notch band width
Hz
0
0~1000
1|3|5|6|7
5.7.7
P2-83
Fifth notch frequency
Hz
5000
50~5000
1|3|5|6|7
5.7.7
P2-84
Fifth notch attenuation
0.1dB
70
50~1000
1|3|5|6|7
5.7.7
P2-85
Fifth notch band width
Hz
0
0~1000
1|3|5|6|7
5.7.7
P3-XX:
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
P3-00
V-REF Function
Allocation
0-V-REF as Speed
Instruction Input
1-V-REF will be used
as input reference
value of external
speed limit. The actual
speed limit depends
on the speed limit of
external analog
quantity.
2-Speed Feedforward
-
0
0~2
1
4.5
P3-01
Analog voltage
corresponding to rated
speed
0.001V
10000
1500~30000
1
4.5
P3-02
Analog voltage speed
filter
0.01ms
0
0~10000
1
4.5
P3-03
Speed instruction
input dead zone
voltage
0.001v
0
0~500
1
4.5
P3-04
V-REF analog speed
direction
-
0
0~1
1
4.5
P3-05
Preset speed 1
rpm
0
-9999~9999
3
4.4.2
P3-06
Preset speed 2
rpm
0
-9999~9999
3
4.4.2
P3-07
Preset speed 3
rpm
0
-9999~9999
3
4.4.2
