Xinje DS3E Series Manual

102
state, monitor U0-10, rotate
motor shaft by hand, U0-10
increase at one direction and
decrease at another direction
(0~9999)
Short circuit with
drive UVW or motor
problem
1. measure the phase resistor
of motor phase UVW, if not
balanced, change the motor
2. If short circuit between
UVW and PE, change the
motor 3. Measure UVW
output with multimeter (diode
gear), black pen test P+, red
pen test UVW, red pen test P-,
black pen test UVW. 6. Group
voltage any one is 0, change
the drive
Load has locked
rotor
Run the motor without load to
check the problem
Interference
Shut down the device with
interference
Alarm at the
moment of
high-speed stop/start
Increase the acceleration time
08
0
E-080
Over
speed(actual
speed ≥
P3-21/P3-22)
Motor speed too fast
1. check if there is external
force make the motor over
speed
2. input command frequency
