Xinje DS3E Series Manual

106
power
overload
over the rated power
2. Check the motor shaft
wiring
1
E-161
The heating
power
overload
Motor overheating
1. Change larger power motor
2. Check the motor shaft
wiring
4
E-164
The bus
capacitor
overload
Power supply not
stable, motor load
too large, cause the
bus capacitor charge
frequently
1. use 3 phase 220V power
supply for 220V drive
2. change larger power motor
5
E-165
locked rotor
alarm (drive
version
U2-23=12.24
&750W and
down model
support)
Locked rotor time
up to P0-70(unit is
second) and motor
speed lower than
P0-71(unit is 1rpm),
motor present output
torque larger than
P3-28, P3-29
1. monitor U0-02 motor
torque, check if P3-28, P3-29
torque limit value is
reasonable
2. check the mechanical
structure
17
0
E-170
Motor
undervoltage
when running
Bus voltage too low
when running
1. check the power grid
voltage fluctuation
2. wait the bus voltage stable,
then repower
20
0
E-200
Regenerative
resistor
overload
Regenerative
resistor discharging
power over the rated
Change larger power
regenerative resistor
1
E-201
Regenerative
resistor
discharge too
Regenerative
resistor connection
error or value too
Change small value resistor
and check the wiring
