Xinje DS3E Series Manual

78
65535
modes
69
Fan switch
0: temperature over
45ºC, fan is ON, below
42ºC, fan is OFF
(hysteresis 3℃)
1: fan is ON after servo
enabled, fan is OFF after
servo is disable
-
1
0~1
○
All the
modes
74
Block alarm time
1S
0
0~9999
○
All the
modes
Note: driver U2-23= 1224, motor block time is P0-70
75
Block alarm speed
1rpm
50
5~9999
○
All the
modes
Note: driver U2-23=1224, motor block speed is P0-71
P1: control parameters
P1-
Name
Unit
Default
Range
Effective
Suitable
mode
00
The gain of first
speed loop
Hz
100
1~9999
√
3,4,6,7,10
01
First speed loop
integral time
0.1ms
400
0~10000
√
3,4,6,7,10
02
The gain of first
position loop
1/s
100
1~9999
√
6, 10
03
First speed
feedback response
level
Hz
1000
0~4000
√
All the
modes
