Xinje DS3E Series

89
output 1 trigger
condition
modes
11
User-defined
output 1 trigger
condition
comparison value
Related to
the trigger
condition
0
-9999~999
9
○
All the
modes
12
0: P5-10≥P5-11,
output SOx
1: P5-10<P5-11,
output SOx
2: P5-10 absolute
value≥ P5-11,
output SOx
3: P5-10 absolute
value <P5-11,
output SOx
-
0
0~3
○
All the
modes
13
User-defined
output 1 hysteresis
loop
Related to
the trigger
condition
0
0~65535
○
All the
modes
14
User-defined
output 2 trigger
condition
-
0
0~FFFF
○
All the
modes
15
User-defined
output 2 trigger
condition
comparison value
Related to
the trigger
condition
0
-9999~999
9
○
All the
modes
16
0: P5-14≥P5-15,
output SOx
-
0
0~3
○
All the
modes
