1: P5-14≤ P5-15,
SOx output
2: P5-14 absolute
value ≥P5-15,
output SOx
3: P5-14 absolute
value <P5-15,
output SOx
17
User-defined
output 2 hysteresis
loop
Related to
the trigger
condition
0
0~65535
○
All the
modes
18
IO filter time
ms
0
0~10000
○
All the
modes
19
Z phase signal
pulse width
ms
2
2~20
√
All the
modes
20
/S-ON servo signal
0000: signal is
always invalid
0001: input
positive signal
from SI1
0002: input
positive signal
from SI2
0003: input
positive signal
from SI3
0004: input
－
n.0001
n.0000~
n.0015
√
All the
modes
