P5- Function Unit
Default
value
Range
Effect
ive
Suitable mode
trigger
conditions
14 Custom Output 2 Trigger Condition - 0 0~ffff √ 1|3|5|6|7|8|9|10
15
Set a value that compares with the trigger
condition of custom output 2
Related to
trigger
conditions
0
-9999~
9999
√ 1|3|5|6|7|8|9|10
16 Select custom output 2 mode - 0 0~3 √ 1|3|5|6|7|8|9|10
17 Setting custom output 2 hysteresis
Related to
trigger
conditions
0 0~65535 √ 1|3|5|6|7|8|9|10
18 IO Filtering time multiple - 1 0~10000 √ 1|3|5|6|7|8|9|10
19 Z phase output maintain time ms 2 1~65535 √ 1|3|5|6|7|8|9|10
20.0~1
/S-ON: servo signal
00: Set the signal to be invalid all the time.
01: Input positive signal from SI1 terminal.
02: Input positive signal from SI2 terminal.
03: Input positive signal from SI3 terminal.
04: Input positive signal from SI4 terminal.
10: Set the signal to always be "valid".
11: Inverse signal is input from SI1
terminal.
12: Inverse signal is input from SI2
terminal.
13: Inverse signal is input from SI3
terminal.
14: Inverse signal is input from SI4
terminal.
- 01 0~ff √ 1|3|5|6|7|8|9|10
20.2 SI terminal filtering time ms 0 0~f √ 1|3|5|6|7|8|9|10
21.0~1 /P-CON proportion action instruction - 00 0~ff √ 1|3|5|6|7|8|9|10
21.2 SI terminal filtering time ms 0 0~f √ 1|3|5|6|7|8|9|10
103
