Motor model
LA±1
LB Inertia level
Normal With brake
MS5G-130STE-C□05415□□-20P8-S01 117.5 147
12.5
Medium
inertia
MS5G-130STE-TL05415□□-20P8-S01 134.5 164.5
MS5G-130STE-C□07220□□-21P5-S01 132.5 162.5
MS5G-130STE-C□07220□□-41P5-S01 132.5 162.5
MS5G-130STE-TL07220□□-21P5-S01 149.5 179.5
MS5G-130STE-TL07220□□-41P5-S01 149.5 179.5
MS5G-130STE-C□11515□□-21P8-S01 159.5 189.5
MS5G-130STE-C□11515□□-41P8-S01 159.5 189.5
MS5G-130STE-TL11515□□-21P8-S01 176.5 206.5
MS5G-130STE-TL11515□□-41P8-S01 176.5 206.5
MS5G-130STE-C□14615□□-22P3-S01 180.5 210.5
MS5G-130STE-C□14615□□-42P3-S01 180.5 210.5
MS5G-130STE-TL14615□□-22P3-S01 197.5 227.5
MS5G-130STE-TL14615□□-42P3-S01 197.5 227.5
MS5G-130STE-C□07330□□-22P4-S01 132.5 162.5
MS5G-130STE-TL07330□□-22P4-S01 149.5 179.5
MS5G-130STE-C□10025□□-22P6-S01 159.5 189.5
MS-130ST-T10015□□-21P5 205 264
14 -MS-130STE-T07730□□-22P4 205 264
MS-130ST-T10025□□-22P6 209 290
MS-130ST-TL10030□□-43P0 225 284 15 -
24
