Xinje DS5E Series Manual

40
2
5
12. 5
57± 0. 5
Ø22h6
Ø110h7
LA
∅
1
4
5
a130
4
-
∅
9
5
6
P9
18. 5
0
- 0. 1
Motor model
LA±1
Inertia level
Normal With brake
MS5G-130STE-C□06025B□-21P5-S01 122 153.5
Medium inertia
MS5G-130STE-C□10015B□-21P5-S01 145 176.5
 MS6 motor
LA
5
Ø110
0
- 0
h7
57
40
Ø22
0
- 0
h6
12. 5
∅145
4- ∅9
8
- 0 - 0. 1
P9
M6 15深
18
0. 0
- 0. 1
Motor model
LA±1
Inertia level
Normal With brake
MS6H-130C□15B□2-20P8 126 156 High inertia
MS6H-130C□15B□2-40P8 126 156
MS6H-130TL15B□2-20P8 142 172
MS6H-130TL15B□2-40P8 142 172
MS6H-130C□15B□2-41P3 148 178
MS6H-130TL15B□2-41P3 164 194
25
