Page #83 background image
discharge starts, U-05 = 660
discharge ends;)
(2) Increasing Acceleration and
Deceleration Time
(3) Reducing load inertia
(4) Reduce start-stop frequency
(5) Replacement of larger power
drivers and motors
Brake resistance
damage or excessive
resistance value
Check the regenerative resistor and
replace the external resistor with the
appropriate resistance value. See
chapter 1.4.1 for the selection of the
external resistor.
Acceleration and
deceleration time is too
short
Extending Acceleration and
Deceleration Time
Hardware Fault of
Driver Internal
Sampling Circuit
The AC gear of the multimeter
measures the input value of the
servo LN (R/S/T), which is 220V ±
10% of the normal value. If the
power supply voltage is more than
220V+10% (380V+10%), check the
power supply voltage; if the power
supply voltage is normal, then the
servo BB state, monitor U0-05, the
voltage measured by the multimeter
* 1.414 < U0-05 (within 10V error),
then the servo driver is faulty and
needs to be sent back for repair.
04 0 E-040 Bus voltage U0-05 is
lower than the actual
preset threshold.
220V power supply
low voltage of power
grid when normal
power on
(1) Check the fluctuation of power
grid. The normal voltage range of
220V driver is 200V~240V. If the
voltage fluctuation is large, the
76
