machine (U0-05 ≤
150V)
380V power supply
machine (U0-05 ≤
350V)
voltage regulator is recommended.
(2) Replacement of larger capacity
transformers
Instantaneous power
failure
Re-energize after voltage
stabilization
Hardware Fault of
Driver Internal
Sampling Circuit
The AC gear of the multimeter
measures the input value of the
servo LN (R/S/T), which is 220V ±
10% of the normal value. If < 220V
+ 10% (380V + 10%), then check
the supply voltage; if the supply
voltage is normal, then servo BB
state, monitoring U0-05, multimeter
measurement voltage * 1.414 > U0-
05 (error within 10V), then the
servo driver is faulty and needs to
be sent back for repair.
1 E-041 Driver power down Driver power off Check the power supply
3 E-043
Bus Voltage Charging
Failure
low voltage of power
grid when normal
power on
low voltage of power grid when
normal power on
Hardware damage
When the driver is on, please pay
attention to whether there is relay
actuation sound.
4 E-044
Phase loss of three-
phase voltage input
Phase loss of three-
phase input power
supply
Check the power supply
6 0 E-060 Module temperature is
too high
(Module temperature
U-06 ≥ 90℃ alarm, U-
06 ≥ 70℃ Warning)
Running under heavy
load for a long time
Re-consider the capacity of the
motor, monitor the U0-02 torque
during operation, whether it is in
the value of more than 100 for a
long time, if yes, please chose the
large-capacity motor or load
77
