Xinje DS5K Series User Manual

MS6S–60 C S 30 B Z 1–2 0P4
Name
Rated
power
0P1 100W
0P2 200W
0P4 400W
Name Voltage level
2 220V
4 380V
Name Motor connector
1 AMP plug
2 Aviation plug
Name Motor shaft
A With Key, no oil seal
B With key and oil seal
Series Inertia
MS6S Low inertia
MS6H High inertia
Display Base No.
60 60 base
80 80 base
Name Encoder type
C Magnetic
T Photoelectric
Name
15
20
Rated speed (Rpm)
1500
2000
Name Encoder bit
S Single turn 17bit
M Multi turn 17bit
U Single turn 23bit
L Multi turn 23bit
25 2500
40 40 base
100 100 base
130 130 base
180 180 base
30
3000
C No key and oil seal
D No key, with oil seal
E Special shaft
0P7 750W
0P8 850W
1P5 1.5KW
1P8 1.8KW
Name
Rated
power
3P0 3.0KW
4P4 4.4KW
5P5 5.5KW
7P5 7.5KW
Name Brake
/ No brake
Z With brake
3
Connector
(for IP67)
2P3 2.3KW
Note: Currently, only the combination of CS, CM, TL, and T is available for encoder type selection!
Standard type 1 refers to an Amp plug of 80 flanges and below.
Standard type 2 refers to a small aviation plug of 80 flanges and below.
