Parameter
Parameter
Setting unit
Default
setting
Suitable
mode
Modify
Effective
P7
-11
Communicati
on
configuration
-
n.2206
All
Servo bb
At once
Parameter set
ting
Function
Default
setting
Range
n.
□
xxx
Parity bit
0
0: no parity
1: odd
2: even
n.x
□
xx
Stop bit
0
0
:
2-bit
2
:
1-bit
n.xx
□□
Baud rate
06
00
：
300
01
：
600
02
：
1200
03
：
2400
04
：
4800
05
：
9600
06
：
19200
07
：
38400
08
：
57600
09
：
115200
0A
：
192000
0B
：
256000
0C
：
288000
0D
：
384000
0E
：
512000
0F
：
576000
10
：
768000
11
：
1M
12
：
2M
13
：
3M
14
：
4M
15
：
5M
16
：
6M
tudonghoatoancau.com
191
193
