Xinje DS5K Series User Manual

2. Cable diameter specification
length
flange
encoder cable diameter
power cable diameter
type
whole
(mm)
separate (mm
2
)
type
whole
(mm)
separate (mm
2
)
≤20m
80
flange
and
below
with/without
battery box
5.8/6.4
3P*0.2mm²
normal/high
flexible
7.2/7.0
4*0.75mm²
110, 130
flange
6.2/6.2
normal/high
flexible
9.4/9.6
4*1mm²
180
flange
2.9KW,
3KW
high flexible
6.2
normal/high
flexible
11.4/11.9
4*2mm²
180
flange
above
3KW
normal/high
flexible
14.5/15.6
4*6mm²
220
flange
22KW
and
below
high flexible
7.9
4P*0.2mm²
normal
19.8
4*10mm²
32KW
normal
20
3*12mm²+1*4mm²
45KW
normal
29
3*30mm²+1*16mm²
25m,
30m
180
flange
and
below
normal/
high flexible
7.8/6.8
2P*0.2mm²+1P*0.34mm²
/
/
/
220
flange
high flexible
7.9
3P*0.2mm²+1P*0.4mm²
/
/
/
3. Cable performance specification
Performance
Normal cable
High flexible cable
Ordinary temperature
resistance
-20℃~80℃
-20℃~80℃
Encoder cable withstand
voltage
1000V/min
1000V/min
Power cable withstand
voltage
3000V/min
3000V/min
Mobile
installation
Bending
radius
Travel ＜10m，7.5*D；
Travel ≥10m，10*D；
Travel ＜10m，7.5*D；
Travel ≥10m，10*D；
Bending
resistance
Travel ＜10m, ≥1 million times；
Travel ≥10m, ≥2 million times；
Travel ＜10m, ≥3 million
times；
