Xinje DS5K Series User Manual

◼ 180 series motor installation dimensions Unit: mm
LA
79±0.5
203
51
2
11
35h6
114.3h7
200
4-
13.5
a180
30
0
-0.1
10
0
-0.03
M12深16
Motor model
LA±1
Inertia level
Normal
With
brake
MS5G-180ST-TL19015□□-42P9-S01
221
303
Medium
inertia
MS5G-180ST-TL28015□□-44P4-S01
247
329
LA
114.3h7
102
20
3
3
42h6
113±0.5
2
200
4-
13.5
a180
37
0
-0.1
12
0
-0.03
M16深16
Motor model
LA±1
Inertia level
Normal
With
brake
MS5G-180ST-TL35015□□-45P5-S01
277
359
Medium
inertia
MS5G-180ST-TL48015□□-47P5-S01
318
400
Ø114.3h7
3
79
20
LA
Ø35h6
65
4-
∅
13.5
□ 180
∅
200
90.15
147.9
132
195
0.1 A
0.08 A
A
0.03 A
10
N9
30
M12深16
Motor model
LA±1
Inertia level
Normal
With
brake
MS6H-180C□15B□2-43P0
215
255
High inertia
MS6H-180TL15B□2-43P0
215
255
MS6H-180C□15B□2-44P4
247
287
MS6H-180TL15B□2-44P4
247
287
