Xinje DS5L Series

P4- Function Unit
Default
value
Range
Effect
ive
Suitable
mode
03.1
Step change mode is set for the given mode of
internal position
0 - step change when the signal is on, which can be
cycled
1 - the rising edge of the signal changes steps and is
executed in one step
2 - the rising edge of the signal starts, and all are
executed in sequence without circulation
3 - Communication setting segment number
4 - / CHSTP double edge trigger
5-terminal / PREFA (P5-57), / PREFB (P5-58), /
PREFC (P5-59) select the segment number, and 1 ~ 3
segments can be selected
6-mode 7: terminal / PREFA (P5-57), / PREFB (P5-
58), / PREFC (P5-59), / PREFD (P5-60) selects
segment number, and 1 ~ 8 segments (3370 version
and before) are optional
Terminal / PREFA (P5-57), / PREFB (P5-58), /
PREFC (P5-59), / PREFD (P5-60) select the segment
number, and 1 ~ 16 segments (3740 version and
later) can be selected
- 0 0~6 ○ 5
03.2
Internal position mode sets waiting mode
0-wait positioning completion
1-not wait positioning completion
- 0 0~1 ○ 5
04 Valid segment number - 0 0~35 ○ 5
08 Internal location mode start segment number - 1 0~35 ○ 5
10
～
11 First segment pulse 1pul 0
-
327689999
~3276799
99
√ 5
101
