Appendix B Function configuration list
The terminal and function of inverter is shown in table 1~3:
Note: ○ user selection × not support √ support
Table 1:
Voltage level Type
Power
(KW)
Current
(A)
Vector
RS485 Brake unit Brake resistor
220V/
1-phase
VB3-20P7 0.75 4.7 × √ No ×
VB5-20P7 0.75 4.7 × √ Built-in 150Ω/200W○
VB5-21P5 1.5 7.5 × √ Built-in 100Ω/400W○
VB5-22P2 2.2 10 × √ Built-in 70Ω/500W○
380V/
3-phase
VB3-40P7 0.75 2.5 √ √ No ×
VB3-41P5 1.5 4.7 √ √ No ×
VB3-42P2 2.2 6 √ √ No ×
VB3-43P7 3.7 9.6 √ √ No ×
VB5-40P7 0.75 2.5 √ √ Built-in 750Ω/100W○
VB5-41P5 1.5 4.7 √ √ Built-in 300Ω/400W○
VB5-42P2 2.2 6 √ √ Built-in 200Ω/500W○
VB5-43P7 3.7 9.6 √ √ Built-in 200Ω/500W○
VB5-45P5 5.5 14 √ √ Built-in 100Ω/500W○
VB5-47P5 7.5 17 √ √ Built-in 75Ω/1000W○
V5-4011 11 25 √ √ Built-in 50Ω/1000W○
V5-4015 15 33 √ √ Built-in 40Ω/1500W○
V5-4018 18.5 38 √ √ Built-in 32Ω/5000W○
V5-4022 22 46 √ √ External (note1) 27.2Ω/5000W○
V5-4030 30 60 √ √ External (note1) 20Ω/6000W○
V5-4037 37 75 √ √ External (note1) 16Ω/9600W○
V5-4045 45 90 √ √ External (note1) 13.6Ω/9600W○
V5-4055 55 110 √ √ External (note1) 10Ω/12000W○
Note1: the external brake unit can select from other company, such as BRU-4045.
