V5 series inverter
50
13. Default setting (Group PF)
Group PP: Default Setting
Parameter Name Range
Minmum
unit
Default
setting
Change
PF.00 Default password - - - *
PF.01 User’s password 0：No password
0001－9999: passwor protection
1 0000 ○
PF.02 Software version - - - *
PF.03～PF.10 Reversed - - - *
14. B Monitor function parameters
B-Monitor function parameters
Code Name Description
Minmum
unit
Factory
setting
Change
b-00 Output frequency Present output frequency 0.01Hz *
b-01 Setting frequency Present setting frequency 0.01Hz *
b-02 Output voltage Valid value of present output voltage 1V *
b-03 Output current Valid value of present output current 0.1A *
b-04 Bus voltage Present DC bus voltage 1V *
b-05 Module temperature IGBT radiator temperature 10C *
b-06 Motor speed Present motor speed 1r/min *
b-07 Operating time Continuous operating time of inverter 1 hour *
b-08 Input/output terminal status Digital input/output terminal status —— *
b-09 Analog input VI Value of analog input VI 0.01V *
b-10 Analog input CI Value of analog input CI 0.01V *
b-11 External pulse input Input value of external pulse width 1ms *
b-12 Inverter rated current Inverter rated current 0.1A *
b-13 Inverter rated voltage Inverter rated voltage 1V *
b-14 no unit dispaly no unit dispaly 1 *
b-15 Inverter power class Inverter power class - *
b-16 Display present counter
value
Display present counter value - *
b-17 Reversed - - *
…… Reversed - - *
b-40 Reversed - - *
Note: The relationship of monitor parameter input/output terminals and their status are shown below:
“ ” means invalid（light is off）， “ ”means valid (light is on)
