Xinje VB5N Series User Manual

VB5N series inverter
37
34: External interrupt input
35: Pulse frequency input
(only valid for X6)
36: Actual length reset
input
P4.01
Function selection of
input terminal X2
Ditto
1
2
×
P4.02
Function selection of
input terminal X3
Ditto
1
3
×
P4.03
Function selection of
input terminal X4
Ditto
1
10
×
P4.04
Function selection of
input terminal X5
Ditto
1
17
×
P4.05
Function selection of
input terminal X6
Ditto
1
18
×
P4.06
Function selection of
input terminal X7 FWD
Ditto
1
0
×
P4.07
Function selection of
input terminal X8 REV
Ditto
1
0
×
P4.08
FWD/REV
Operation mode selection
0: 2-wire control mode 1
1: 2-wire control mode 2
2: 3-wire control mode 1
3: 3-wire control mode 2
1
0
×
P4.09
UP/DOWN speed
0.01－99.99Hz/s
0.01
1.00Hz/s
○
P4.10
Bi-direction
open-collector output
terminal OC
0: Inverter running (RUN)
1: Frequency arriving sig-
nal (FAR)
2: Frequency level detec-
tion (FDT1)
3: Frequency level detec-
tion (FDT2)
4: Overload pre-alarm (OL)
5: Inverter under voltage
blockade and stop (LU)
6: External fault stop
(EXT)
7: Output frequency arrive
upper limit (FH)
8: Output frequency arrive
lower limit (FL)
9: Inverter zero speed run-
ning
10: Simple PLC running
finished
11: PLC one period run-
ning is completed
12:reach the setting count
value
13: Mid counting value
1
0
×
