Xinje VB5N Series User Manual

VB5N series inverter
38
arrived
14: Inverter running prepa-
ration is finished (RDY)
15: Inverter fault
16: Running with start
frenquence
17: DC brake when startup
18: brake when stop
19: High and low limit of
swing frequency
20: set running time arrived
P4.11
Relay output selector
Ditto
1
15
×
P4.12
Detecting range of fre-
quency arrived (FAR)
0.00~50.00Hz
0.01Hz
5.00Hz
○
P4.13
FDT1 (frequency) volt-
age
0.00~upper limit of of fre-
quency
0.01Hz
10.00Hz
○
P4.14
FDT1 lag
0.00~50.00Hz
0.01Hz
1.00Hz
○
P4.15
FDT2 (frequency) volt-
age
0.00~upper limit of of fre-
quency
0.01Hz
10.00Hz
○
P4.16
FDT2 lag
0.00~50.00Hz
0.01Hz
1.00Hz
○
P4.17
Analog output (AO)
0: Output frequency
(0~max frequency)
1: Output current (0~2
times of rated current)
2: Output voltage (0~1.2
inverter rated voltage)
3: Bus voltage (0~800V)
4: PID setting
5: PID feedback
6: VI (0~10V)
7: CI (0~10V/4~20mA)
1
0
○
P4.18
Analog output (AO) gain
0.50~2.00
0.01
1.00
○
P4.19
AO output mode
0: 4~20mA
1: 0~10V
-
1
○
P4.20
DO output terminal
0: Output frequency
(0~upper limit frequency)
1: Output current (0~2
times motor rated current)
2: Output voltage (0~1.2
inverter rated voltage)
3: Bus voltage (0~800V)
4: PID setting
5: PID feedback
6: VI (0~10V)
7: CI (0~10V/4~20mA)
100: inverter is running
(RUN)
101: frequency reach signal
1
0
○
