Xinje VB5N Series User Manual

VB5N series inverter
61
4-2-5. Function parameters of terminal (Group P4)
P4.00
Function selection of input terminal X1
Range: 0~37
1
P4.01
Function selection of input terminal X2
Range: 0~37
2
P4.02
Function selection of input terminal X3
Range: 0~37
3
P4.03
Function selection of input terminal X4
Range: 0~37
10
P4.04
Function selection of input terminal X5
Range: 0~37
17
P4.05
Function selection of input terminal X6
Range: 0~37
18
P4.06
Function selection of input terminal X7
Range: 0~37
0
P4.07
Function selection of input terminal X8
Range: 0~37
0
Multi-function input terminals X1~X8 support various functions. You can define the function of X1~X8 by setting
the value of P4.00~P4.07, refer to Table 4-1. Among these terminals, X7 corresponds to FWD and X8 corresponds to
REV.
Table 4-1 Multi-function selection
Setting
Functions
Setting
Functions
0
Control terminals are idle
19
Frequency setting channel 1
1
Multi-speed choice terminal 1
20
Frequency setting channel 2
2
Multi-speed choice terminal 2
21
Frequency setting channel 3
3
Multi-speed choice terminal 3
22
Command switch to terminal
4
Exteral forward jog input
23
Running command channel selection 1
5
Exteral reverse jog input
24
Running command channel selection 2
6
Acc/Dec time terminal 1
25
Swing frequency input
7
Acc/Dec time terminal 2
26
Swing frequency reset
8
Acc/Dec time terminal 3
27
Close-loop is invalid
9
3-wire operation control
28
Pause the simple PLC operation command
10
Free stop input (FRS)
29
PLC is invalid
11
External stop command
30
Reset PLC stopping status
12
DC brake input command DB
31
Frequency switch to CI
13
Inverter running prohibition
32
Counter trigger signal input
14
Frequency increase (UP)
33
Counter reset signal input
15
Frequency decrease (DOWN)
34
External interrupt input
16
Acc/Dec prohibition
35
Pulse frequency input (only valid for X6)
17
External reset signal (clear the fault)
36
Autual length reset
18
External fault input (normal open)
37
Introductions of the functions shown in Table4-1:
1~3: Multi-speed control terminals. Up to 7 kinds of speed can be set by different ON/OFF (open/close) combination of
the function terminals, at the same time, you can select corresponding Acc/Dec time.
Table 4-2 On/Off combination of function terminals
