(HSD108+20*(N-1)) will change.
● when the motor enabled, it can clear the parameters in table 1 and 2.
● there are four methods to change the present position:
① return to origin through (SM2014+20*(N-1)), (SM2015+20*(N-1)), the present
position will change.
② when PLC stop, modify the target position feedback pulse numbers (+20*(N-1)), the
present position will change
③ when PLC is running, execute MOWRITE can modify (HSD104+20*(N-1)), the
present position will change.
④ when PLC is running, servo does not enable, the servo position is chagned by
external force, register (HSD104+20*(N-1)) will change. When the servo enabled, this value is
valid.
Table 1: state quantity parameters (N=1~10)
Address
Definition
Type
Unit
Mark
SD2006+
60*(N-1)
Present
displacement
quantity
32-bit
integer
Pulse
number
The displacement relative to the last stop
position
SD2008+
60*(N-1)
Present
position
32-bit
integer
Pulse
number
The coordinate position, calculated from
target position feedback pulse numbers
Table 2: self preserving state (N =1~10)
Address
Definition
Type
Unit
Mark
HSD100+
20*(N-1)
Target position setting
pulse numbers
64-bit
integer
Encoder
count
Relative zero position
HSD104+
20*(N-1)
Target position
feedback pulse
numbers
64-bit
integer
Encoder
count
Relative zero position
HSD108+
20*(N-1)
Present displacement
pulse numbers
64-bit
integer
Encoder
count
Single time motion
instruction displacement
quantity
Related register
