5: xinje encoder
SD2004+
60*(N-1)
(double
words)
Fieldbus
communic
ation error
times
(1) Check the servo drive
parameters P7
(2) Check the communication
cable between PLC and servo
Appendix 1 XINJE config software
 XINJEConfig installation
1. Please contact us to get this software. Generally, user can find it in the XD software installation
package.
2. install the software according to the guide.
 Use XINJEConfig
Please connect PLC with PC through USB cable before using XINJE config.
USB cable can work after the driver is installed which will be installed together with the XINJE
config.
1. Open the XINJE config, it will show the following window:
2. Click “config”-Finddevice, it will show Form_ChooseCompot window.
