Xinje X-NET fieldbus User Manual

S4
Target object address (refer to
chapter 1-3)
32 bits constant or double words register
S5
Access object numbers
16 bits constant or single word register
S6
Local object address
Local register
3. Suitable soft component
*Note: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS.
M includes M, HM; S includes S, HS; T includes T, HT; C includes C, HC.
Intruction
REG_WRITE K2 K5 K0 K10
X0
D0
S1· S2· S3· S4· S5·
K128
S6.
Function: write the local register D0~D9 to station no.5 D0~D9 in ID2 network.
1-3. Communication address
The X-NET address of PLC soft components:
XD3 soft component address:
Type
Name
Soft component
address
Type
code
Quantity
X-NET
address
(decimal)
X-NET address
(hex)
Coil,
bit
X
X0~X77 (PLC)
1
64
0~63
0~3F
X10000~X10077
(module 1)
64
4096~4159
1000~103F
X10100~X10177
(module 2)
64
4160~4223
1040~107F
X10200~X10277
(module 3)
64
4224~4287
1080~10BF
X10300~X10377
(module 4)
64
4288~4351
10C0~10FF
X10400~X10477
64
4352~4415
1100~113F
Operand
System
Constant
Module
D
*
FD
TD
*
CD
*
DX
DY
DM
*
DS
*
K /H
ID
QD
S1
●
●
●
●
●
S2
●
●
●
●
●
S3
●
●
●
●
●
S4
●
●
●
●
●
S5
●
●
●
●
●
S6
●
●
●
●
Word
