Xinje X-NET fieldbus - Page 16

(module 5)
X10500~X10577
(module 6)
64
4416~4479
1140~117F
X10600~X10677
(module 7)
64
4480~4543
1180~11BF
X10700~X10777
(module 8)
64
4544~4607
11C0~11FF
X11000~X11077
(module 9)
64
4608~4671
1200~123F
X11100~X11177
(module 10)
64
4672~4735
1240~127F
X20000~X20077
(BD 1)
64
8192~8255
2000~203F
Y
Y0~77 (PLC)
2
64
0~63
0~3F
Y10000~Y10077
(module 1)
640
4096~4159
1000~103F
Y10100~Y10177
(module 2)
64
4160~4223
1040~107F
Y10200~Y10277
(module 3)
64
4224~4287
1080~10BF
Y10300~Y10377
(module 4)
64
4288~4351
10C0~10FF
Y10400~Y10477
(module 5)
64
4352~4415
1100~113F
Y10500~Y10577
(module 6)
64
4416~4479
1140~117F
Y10600~Y10677
(module 7)
64
4480~4543
1180~11BF
Y10700~Y10777
(module 8)
64
4544~4607
11C0~11FF
Y11000~Y11077
(module 9)
64
4608~4671
1200~123F
Y11100~Y11177
(module 10)
64
4672~4735
1240~127F
Y20000~Y20077
(BD 1)
64
8192~8255
2000~203F
M
M0~M7999
3
8000
0~7999
0~1F3F
S
S0~S1023
4
1024
0~1023
0~3FF
T
T0~T575
5
576
0~575
0~23F
C
C0~C575
6
576
0~575
0~23F
ET
ET0~ET31
7
32
0~31
0~1F
HM
HM0~HM959
8
960
0~959
0~3BF
HS
HS0~HS127
9
128
0~127
0~7F
