Installing the Vent Mount:
1 Locate a vent with horizontal
louvers sturdy enough to hold your
PowerConnect Vehicle Dock and Radio.
2 If the vent louvers in your vehicle are
recessed, you may need to use the
longer vent clamps with the Vent Mount.
If so, remove the shorter vent clamps
and install the longer ones into the Vent
Mount. Be sure to observe the orientation of the vent clamps
as shown.
3 Push the Vent Mount onto the vehicle vent as shown (1) until it hooks on
the rear of the vent louver (2).
4 Rest the foot against the bottom of the vent (2), and adjust the tilt of the
Vent Mount by repositioning the foot to a different adjustment hole (3).
To remove the Vent Mount, push the mount into the vent. Then lift up until
disengaged from the rear of the vent louver, and remove the Vent Mount.
PUSH
Dash
Vent
Louver
Foot
Vent
Vent
Dash
Dash
HOOKED
TILT
ADJUSTMENT
HOLES
1 2 3
Slide Short Vent Clamps Out
To Next Page
