38 39
Step 6: Connect the Audio
To play XM audio through your vehicle’s stereo or FM radio, decide on one of the
following audio connection options:
Option 1: Best: Use the provided Aux In Cable if your vehicle’s stereo
system has an auxiliary input connection or jack. Refer to your vehicle’s
owners manual to find the location of the auxiliary input jack, or consult the
vehicle dealer.
TIP! The auxiliary input jack may be located on the face plate of the vehicle
radio, on the back of the radio, anywhere on the front dash panel, inside the
glove compartment, or inside the center console in between the front seats.
Option 2: Better: Use a Cassette Adapter if your vehicle has a built-
in cassette player. Cassette Adapters are sold separately and can be
purchased from an electronics retailer, or go to xmradio.ca.
Option 3: Good: Use the PowerConnect feature of Edge. PowerConnect
plays the audio through your vehicles FM radio.
Option 4: Best: Use the FM Direct Adapter. If none of the previous three
audio connection options will work in your vehicle, then you will need to
use the FM Direct Adapter (FMDA) (sold separately). The FMDA needs to
be installed by a professional installer and directly connects Edge to your
vehicles FM radio. To learn more, check with the retailer where you bought
your Radio, or go to www.xmradio.ca.
Follow the installation instructions in the next several sections for the audio
connection option that you have selected.
Vehicle Installation
Option 1: Aux In Cable Installation Instructions
1 Plug one end of the Aux In Cable into the green AUDIO connector on
the dock.
2 Plug the other end into the
auxiliary input jack of your
vehicles stereo system.
3 Attach the dock to the mount.
4 Insert your Edge into the dock.
5 Power on your Edge by
pressing the Power button.
6 Be sure the vehicle is outside and the antenna has a clear view of the
sky. Verify that you are receiving the XM signal.
There should at least be one bar on the upper left
corner of the main display screen that denotes
antenna signal strength. You can also press
menu and then turn the Rotary Knob to scroll to
and highlight Signal Indicator. Press the Select
button. The Satellite and Terrestrial bars show the
strength of the signal being received. If the signal
AUDIOANT PWR FM
