Edge Button Functions PowerConnect Vehicle Dock
Colour-Coded Connections
The colour-coded PowerConnect Vehicle Dock makes it simple to connect.
Just match the colours on the cable ends to the colours on the dock to see
what goes where.
ANT (Silver)
Connection for
the Magnetic
Mount Antenna.
AUDIO (Green)
Connection for Aux In
Cable or optional
Cassette Adapter
(sold separately).
Rear View
PWR (Red)
Connection for
PowerConnect
Power Adapter.
FM (Blue)
Connection for
optional FM Direct
Adapter (sold
separately).
AUDIO ANT PWR FM
Introduction
6
jump
fmmenu
7 8 9 0
#
1 2 3 4 5
Power Button
Press to turn Radio
on and off.
Left and Right Buttons
Press to search for
channels by category.
Menu Button
Press to access advanced
features and configuration
options; in configuration
options, press and hold
to return to main display
screen.
Select Button
Press to confirm
selection of highlighted
items in a menu or list,
and of settings.
FM Button
Press to access and cycle
through FM presets.
Jump Button
Press to directly access
traffic and weather for the
city of your choice; or press
it to go back to the previous
channel to which you were
listening.
Direct Button
Press first before
entering the channel
number, to directly
tune to a channel.
Number Buttons
Press to tune to
a stored favourite
channel, press and
hold to store a
favourite channel;
also enter a channel
number.
Rotary Knob
Rotate to preview and tune
to channels through the
channel lineup; also scroll
through lists and highlight
menu options.
Pause and Replay Buttons
Pause, rewind, and replay
up to 30 minutes of live
radio.
