In the top part of the screen are the 8 slot – rows. From the left the slot number, followed by the
assigned function (empty if no function is assigned to the slot). Next is the indication whether this
slot/function is running or not. The 8 tracks next to it define to which function of the track the output
is ‘routed’. In the picture you can see that the LFO in slot 0 is routed to the MOD output of Track 3.
In fact, in the picture an LFO is modulating the Physical MOD3 output. In the middle of the screen
you can see the animation of the currently selected Automator.
The lower part shows possible settings of an Automator. The screenshot shows the LFO with all it’s
settings.
For the current version these are the following Automator functions:
• LFO
• Envelope
• CV Input/Output
The destinations in the modulation matrix for the CV/Gate tracks are:
• CV Output → modulates the function onto the CV output
• MOD Output → modulates the function onto the MOD output)
• Trigger Length → overrules the next trigger setting with a ON/OFF trigger where the length
of the trigger is decided by the Automator output (10 .. C0)
• Delayed Trigger/Gate length → overrules the next trigger setting with a OFF/ON trigger /
gate where the length of the delay is decided by the Automator output (01 .. 0F)
• FX1..FX4 Overrule → Overrules the next FX of the defined FX column by the value of the
Automator
• CV Glide → Manipulates the Glide setting for the CV output
• CV Steps → Manipulates the Glide Steps setting for the CV output
• MOD Glide → Manipulates the Glide setting for the MOD output
• MOD Steps → Manipulates the Glide Steps setting for the MOD output
• CV/Trigger/MOD/Table/FX1..4/Row Probability → Manipulates the probability settings for
the defined FX
• Step Overrule → Overrules the current step in the currently playing pattern. This is an
experimental function.
• Gate → Sets or resets the gate of the selected track. If the automator value is higher than 0
then it Sets and if the automator value is lower than 1 then it resets the Gate.
The destinations for the audio tracks 7+8 are:
NerdSEQ – a tracker based Eurorack sequencer Page 74
User Manual Revision V1.26 for Firmware V1.26 12 July 2022
