43
VIDEO TECH TIP
▶
WEIGHT BALANCE
VIDEO TECH TIP
▶
BATTERY MOUNTING
SYSTEM
902320
SH M3x20
901305
SB M3x5
7. FINAL ASSEMBLY
OPTIONAL WEIGHTS
NOTE ORIENTATION
To ensure correct functioning of the battery
holder, do not overtighten the screw; the holder
must be able to move.
HEIGHT ADJUSTMENT
1 turn = 0.5mm
(4g)
(4g)
(8g)
#309852
X4 BRASS WEIGHTS NICKEL COATED FOR MOTOR
MOUNT 4g+4g+8g
#306551
XRAY PURE TUNGSTEN
CHASSIS WEIGHT 11g
